Specifications

FeatureDescription
Header Capacity (ft)41
Total Length (ft)49 (including gooseneck, dolly, and telescopic hitch)
Overall Width (in)95
Frame MaterialSteel
Main Frame Size4x4
Incline Frame DesignIncline
Number of Brackets4
Bracket TypeAdjustable
Axle TypeFixed
Axle Quantity2
Axle Rating (lbs)7,000 each
Dolly TypeSwivel front dolly
Dolly Axle Rating (lbs)7,000
Wheel / Tire SizeST235/80R16
Tire Ply Rating10-ply (16-ply optional)
BrakesNone
LightsNone
Shipping Weight lbs3,718 lbs
GVWR (lbs)21,000

The 441 adds just a touch more length for 41’ headers but keeps the same heavy 4x4 incline frame and tandem 7k axle layout as the rest of the bigger 4-Series. It’s aimed at producers moving larger platforms who still want a simple, fixed-axle design without torsion or brake systems to maintain. With four adjustable brackets and a swivel dolly, the header stays put and the trailer is easy to handle in tight farmyards and field entrances.

×
