Specifications
| Feature | Description |
|---|---|
| Header Capacity (ft) | 32 |
| Total Length (ft) | 40.5 (including gooseneck, dolly, and telescopic hitch) |
| Overall Width (in) | 95 |
| Frame Material | Steel |
| Main Frame Size | 8x4 |
| Incline Frame Design | Incline |
| Number of Brackets | 4 |
| Bracket Type | Adjustable |
| Axle Type | Torsion |
| Axle Quantity | 2 |
| Axle Rating (lbs) | 6,000 each |
| Dolly Type | Swivel front dolly with plastic fenders and 6.5'–10.5' telescopic hitch |
| Dolly Axle Rating (lbs) | 7,000 |
| Suspension Type | Torsion |
| Wheel / Tire Size | ST235/80R16 |
| Tire Ply Rating | 10-ply (16-ply optional) |
| Brakes | Yes (electric) |
| Brake Axle(s) | 1 axle |
| Lights | Rear lights |
| Shipping Weight lbs | 3,784 lbs |
| GVWR (lbs) | 19,000 |
The 832 is a workhorse for 32’ heads, combining the strength of an 8x4 frame with the smooth ride of torsion axles. It’s built with commercial-style details but sized right for typical row-crop and small grain headers. With four adjustable brackets, you can dial in support for rigid, flex, or draper heads so the weight is carried on the frame instead of the feeder house. On the road, the torsion suspension and electric brakes on one axle give you better control in stop-and-go traffic or when dropping down into ditches and approaches. The front dolly, plastic fenders, and telescopic hitch give you enough maneuverability to back into tight sheds or hook up at odd angles in the yard. If you’re regularly hauling a 32’ head between farms or to the dealer, the 832 is a solid “hook it and go” solution.
